Dahua Technology Pro Series DH-TPC-BF5400N-B Thermal Network Bullet Camera with 25mm Lens


SKU: 5400N Categories: , , Tags: ,


Dahua Technology DH-TPC-BF5400 Specs

Camera Type Thermal
Image Sensor Uncooled VOx Microbolometer
Effective Pixels (H x V) 400 x 300
Pixel Size 17 µm
Thermal Sensitivity (NETD) 40 mK at f/1.0
Spectral Range 7 to 14 µm
Image Settings Brightness, Sharpness, ROI, AGC, FFC, 3D-DNR
Color Palette 14 Color Palettes Including Whitehot, Blackhot, Ironrow, Icefire, Fusion, Rainbow, Globow, Iconbow1, Iconbow2 & More
Type Fixed Thermal Lens
Focus Control Athermalized, Focus-Free
Focal Length 25mm
Horizontal Field of View (degree) 15.5°
Vertical Field of View (degree) 11.6°
Compression H.264, MJPEG
Frame Rate Main Stream: 1280 x 1024 (Default), 1280 x 720 at up to 30/25 fps
Sub Stream: 640 x 512 (Default), 320 x 256 at up to 30/25 fps
Bit Rate Control CBR, VBR
Bit Rate H.264: 640 to 8192 kb/s
Motion Detection Off/On (4 Zone, Rectangle)
Region of Interest Off/On (4 Zone)
Digital Zoom 19x
Mirror Off/On
Privacy Masking Off/On (4 Area, Rectangle)
Compression G.711a, G.711Mu, AAC
Smart Functions
Intelligent Video Analytics Intelligent Video System (IVS): Tripwire, Intrusion, Object Abandon/Missing
Intelligent Function Fire Detection & Alarm
Ethernet 10/100M RJ45
Protocols IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPoE, DDNS, FTP, IP Filter, QoS, Bonjour, 802.1x
Interoperability ONVIF Profiles S & G, PSIA, CGI
Streaming Method Unicast and Multicast
Maximum User Access 10/20 Users
Edge Storage microSD Cards up to 256 GB (Available Separately)
Memory Status Display (Normal, Error, Active, Formatting, Lock)
NAS, Local PC for Instant Recording
Web Viewer Internet Explorer 11 or Below, Chrome 45 or Below, Firefox 52 or Below
Management Software SmartPSS, DSS
Mobile iOS, Android
Video 1.0 V p-p/75 Ohms, PAL/NTSC (HD-CVI Optional)
Audio 1 Input / 1 Output
RS-485 Supported
Alarm 2 Inputs, 1 Output
Power Supply 24 VAC, 12 VDC, PoE
Maximum Power Consumption 11 W
Operating Temperature -40 to 140°F / -40 to 60°C
Start up Should Be Done At Above – 40°F / -40°C
Operating Humidity Less Than 95% RH
Storage Temperature -40 to 158°F / – 40 to 70°C
Storage Humidity Less Than 95% RH
IP Rating IP67
Lightning Protection 6 kV
Certifications CE (EN 60950: 2000), FCC (FCC Part 15 SubpartB)
Casing Material Metal
Dimensions 11.46 x 4.06 x 3.82″ / 291 x 103 x 97 mm
Weight 3.31 lb / 1.5 kg
